Appendix E — Mouse and Keyboard Commands

Mouse commands and conventions

The following mouse click actions are available:

Left-click Selects the active element.
Right-click Toggles the display of the corresponding setup menu for the item beneath the current mouse location.
Modifier + click Ctrl-click is equivalent to right-click. Inside a setup menu item, Alt-click resets the corresponding setting to its default value. Alt-click inside an item with a zoom factor greater than one, resets the current zoom to full view (Factor = 1).
Double-click Double-clicking on an editable control such as a slider or text box enters keyboard entry mode, double-clicking again validates the new value. Double-clicking anywhere inside a panel switches the panel to full-window mode, where the whole application screen is occupied by the corresponding panel; double-clicking a second time reverts to the normal layout.
Click and drag Click + drag inside an item with a zoom factor greater than one shifts the current scale. Alt + Click + drag inside an item with a Zoom Factor allows to setup a new zoom according to the defined selection. See Figure E.1 below.
Scroll wheel + click and drag Turning the middle mouse wheel, if present, affects the current horizontal zoom level of the item under the cursor. Activating the wheel with the middle button simultaneously engaged shifts the current scale when the current zoom factor is greater than one.

On spectrum

On IR plots
Figure E.1: Click and drag behavior

Keyboard shortcuts

MiRA

Action Shortcut
About MiRA F1
Main settings Cmd + , on macOS, Ctrl + P on Windows
IO settings Alt + , on macOS, Alt + P on Windows
UI settings Cmd + Alt + , on macOS, Cmd + Alt + , on Windows

File

Action Shortcut
New workspace Ctrl/Cmd + N
New workspace from factory template Alt + Ctrl/Cmd + N
Open workspace Ctrl/Cmd + O
Save workspace Ctrl/Cmd + S
Save workspace as Ctrl/Cmd + Shift + S
Reload workspace Ctrl/Cmd + R

Edit

Action Shortcut
Show workspace toolbar Ctrl/Cmd + L
Edit current Ctrl/Cmd + Shift + L
Refresh network connection F5
Toggle generator on/off G
Take offset T
Reset offset R
Mic delay add Add
Mic delay subtract Subtract

View

Action Shortcut
Load previous layout Shift + Tab
Load next layout Tab
Load layout 1 Shift + Alt + 1
Load layout 2 Shift + Alt + 2
Load layout 3 Shift + Alt + 3
Load layout 4 Shift + Alt + 4
Load layout 5 Shift + Alt + 5
Load layout 6 Shift + Alt + 6
Load layout 7 Shift + Alt + 7
Load layout 8 Shift + Alt + 8
Load layout 9 Shift + Alt + 9
Load layout 10 Shift + Alt + 0
Close setup Escape
Update mouse infos F6
Always on top F8
Toggles display of realtime curves Return

Help

Action Shortcut
Rebuild GUI Shift + Ctrl/Cmd + F5
Show/hide terminal F7
Show/hide terminal (mini) Shift + F7
Popup terminal Ctrl/Cmd + F7
FOSS - Credits F2
User guide Ctrl/Cmd + H
Show/hide tooltips Shift + Ctrl/Cmd + H

Session

Action Shortcut
New session Shift + Ctrl/Cmd + N
Import session Shift + Ctrl/Cmd + I
Export session Shift + Ctrl/Cmd + E
Duplicate selected captures in session Ctrl/CMD + D
Duplicate session Shift + Ctrl/Cmd + D
Delete session Del/Backspace
Capture in new session Shift + Ctrl/Cmd + Space
Capture with pink noise in new session Shift + Ctrl/Cmd + P
Capture with sweep in new session Shift + Ctrl/Cmd + W

Capture

Action Shortcut
New capture Space
New automated capture with pink noise Shift + P
New automated capture with sweep Shift + S
Capture computed curve Shift + C
Invert capture Shift + R
Import capture Shift + I
Export capture audio to .wav file Shift + Alt + E
Delete capture Del/Back
Update capture setting Shift + U
Decrease the delay by one sample F3
Increase the delay by one sample F4
Decrease the delay by ten sample Shift + F3
Increase the delay by ten sample Shift + F4
Find delay Shift + F
Regenerate color Shift + G
Edit notes Shift + N

Generator

Action Shortcut
Toggle generator on/off G
Next Output Shift + O
Previous output Shift + L

Meters

Action Shortcut
Refresh all meters M

Metering history

Action Shortcut
Set Timecode offset T
Reset Timecode offset R
